1. 前言

alt text

etcd 是一个分布式可靠的键值存储，也是云原生技术的基石，但我在过去几年也没有什么直接操作 etcd 的机会…..只有遇到严重问题时，比如：

etcd 脑裂：ARM64 虚拟机时间同步导致的 etcd 集群异常
etcd 写入超时：ARM64 虚拟机的云盘 IO 性能较差以及 CPU 性能太弱导致的写入时间过长
etcd 数据丢失：运维人员误操作直接销毁数据库节点

才需要挺身而出救火，导致 etcd 相关知识长期处于容易遗忘的状态，因此这里做一些笔记，防患于未然。

下面会使用 etcd 版本为 3.5.15，API 版本为 3.5，官方文档为：v3.5 docs。

2. etcdctl

V2 版本时我们还可以直接使用 curl 通过 HTTP+JSON 的方式调用 etcd 接口进行操作，但从 V3 开始，gRPC+protobuf 取代了 HTTP+JSON 的通信方式，我们只能使用 etcdctl 或者再部署一个 gRPC gateway 来继续保持对 HTTP JSON 接口的支持，这里就讲一讲如何更好地使用 etcdctl。

etcd 的文档提提到 Global flags (e.g., dial-timeout, --cacert, --cert, --key) can be set with environment variables，具体对应的是 etcdctl 帮助命令中输出的 OPTIONS，如下：

OPTIONS:
      --cacert=""				verify certificates of TLS-enabled secure servers using this CA bundle
      --cert=""					identify secure client using this TLS certificate file
      --command-timeout=5s			timeout for short running command (excluding dial timeout)
      --debug[=false]				enable client-side debug logging
      --dial-timeout=2s				dial timeout for client connections
  -d, --discovery-srv=""			domain name to query for SRV records describing cluster endpoints
      --discovery-srv-name=""			service name to query when using DNS discovery
      --endpoints=[127.0.0.1:2379]		gRPC endpoints
  -h, --help[=false]				help for etcdctl
      --hex[=false]				print byte strings as hex encoded strings
      --insecure-discovery[=true]		accept insecure SRV records describing cluster endpoints
      --insecure-skip-tls-verify[=false]	skip server certificate verification (CAUTION: this option should be enabled only for testing purposes)
      --insecure-transport[=true]		disable transport security for client connections
      --keepalive-time=2s			keepalive time for client connections
      --keepalive-timeout=6s			keepalive timeout for client connections
      --key=""					identify secure client using this TLS key file
      --password=""				password for authentication (if this option is used, --user option shouldn't include password)
      --user=""					username[:password] for authentication (prompt if password is not supplied)
  -w, --write-out="simple"			set the output format (fields, json, protobuf, simple, table)

虽然 etcdctl 没有支持使用配置文件来配置默认参数，但可以通过环境变量设置 Global flags，例如需要使用 V3 版本 API，连接到三个指定的服务器，并设置默认的根证书、客户端证书与密钥，可以配置环境变量如下：

export ETCDCTL_API=3
export ETCDCTL_ENDPOINTS=192.168.123.101:2379,192.168.123.102:2379,192.168.123.103:2379
export ETCDCTL_CACERT=/etc/etcdctl/cacert.pem
export ETCDCTL_CERT=/etc/etcdctl/cert.pem
export ETCDCTL_KEY=/etc/etcdctl/key.pem

这样就可以直接使用 etcdctl 命令访问服务器，不需要添加额外的命令行参数，也能减少误操作：

➜  ~ etcdctl member list
96224218d3d7de4, started, machine-3, http://192.168.123.103:2380, http://192.168.123.103:2379, false
d32a4b16a0f9191, started, machine-1, http://192.168.123.101:2380, http://192.168.123.101:2379, false
47c5ecfae8fccdb1, started, machine-2, http://192.168.123.102:2380, http://192.168.123.102:2379, false

3. etcd

3.1 单节点

为了方便测试，我制作了一个 3.5.15 版本的容器镜像：wbuntu/etcd:3.5.15，默认使用单节点模式，使用到的 Dockerfile 和启动脚本如下：

Dockerfile

FROM alpine:3.18
ARG TARGETARCH
RUN apk add --no-cache git zsh
RUN sh -c "$(wget -O- https://raw.githubusercontent.com/ohmyzsh/ohmyzsh/master/tools/install.sh)"
VOLUME /data
WORKDIR /data
COPY ${TARGETARCH}/* /usr/bin/
COPY standalone.sh /usr/bin/standalone.sh
CMD ["/usr/bin/standalone.sh"]

standalone.sh

#!/bin/sh
NAME=$(hostname)
etcd \
  --name ${NAME} \
  --data-dir etcd \
  --listen-client-urls http://0.0.0.0:2379 \
  --advertise-client-urls http://0.0.0.0:2379 \
  --listen-peer-urls http://0.0.0.0:2380 \
  --initial-advertise-peer-urls http://0.0.0.0:2380 \
  --initial-cluster ${NAME}=http://0.0.0.0:2380 \
  --initial-cluster-token tkn \
  --initial-cluster-state new

使用以下命令可以直接启动单节点 etcd：

docker run --name etcd -d --restart unless-stopped -p 2379:2379 -p 2380:2380 -v etcd-data:/data wbuntu/etcd:3.15.15

可以进入容器可以查看 etcd 状态：

➜  ~ docker exec -it etcd zsh
➜  /data etcdctl member list -w=table
+------------------+---------+--------------+---------------------+---------------------+------------+
|        ID        | STATUS  |     NAME     |     PEER ADDRS      |    CLIENT ADDRS     | IS LEARNER |
+------------------+---------+--------------+---------------------+---------------------+------------+
| 59a9c584ea2c3f35 | started | 3a5b5ccf6ca6 | http://0.0.0.0:2380 | http://0.0.0.0:2379 |      false |
+------------------+---------+--------------+---------------------+---------------------+------------+
➜  /data etcdctl endpoint status -w=table
+----------------+------------------+---------+---------+-----------+------------+-----------+------------+--------------------+--------+
|    ENDPOINT    |        ID        | VERSION | DB SIZE | IS LEADER | IS LEARNER | RAFT TERM | RAFT INDEX | RAFT APPLIED INDEX | ERRORS |
+----------------+------------------+---------+---------+-----------+------------+-----------+------------+--------------------+--------+
| 127.0.0.1:2379 | 59a9c584ea2c3f35 |  3.5.15 |   20 kB |      true |      false |         2 |          4 |                  4 |        |
+----------------+------------------+---------+---------+-----------+------------+-----------+------------+--------------------+--------+

3.2 多节点

单节点 etcd 只适合开发测试场景，生产环境中一般至少使用三节点或者五节点的 etcd 来实现高可用，这里使用 cluster.sh 脚本作为启动脚本在三台机器上部署 etcd：

cluster.sh

#!/bin/sh

TOKEN=tkn
CLUSTER_STATE=new
NAME_1=machine-1
NAME_2=machine-2
NAME_3=machine-3
HOST_1=192.168.123.101
HOST_2=192.168.123.102
HOST_3=192.168.123.103
CLUSTER=${NAME_1}=http://${HOST_1}:2380,${NAME_2}=http://${HOST_2}:2380,${NAME_3}=http://${HOST_3}:2380

THIS_NAME=${NAME_1}
THIS_IP=${HOST_1}
etcd \
  --name ${THIS_NAME} \
  --data-dir etcd \
  --listen-client-urls http://${THIS_IP}:2379 \
  --advertise-client-urls http://${THIS_IP}:2379 \
  --listen-peer-urls http://${THIS_IP}:2380 \
  --initial-advertise-peer-urls http://${THIS_IP}:2380 \
  --initial-cluster ${CLUSTER} \
  --initial-cluster-state ${CLUSTER_STATE} \
  --initial-cluster-token ${TOKEN}

三台机器分别对应 NAME_1～NAME_3 与 HOST_1～HOST_3，将脚本中的 THIS_NAME 与 THIS_IP 分别替换后拷贝到三台机器上，然后挂载到容器内运行，这里直接使用宿主机网络简化配置：

docker run --name etcd -d --restart unless-stopped --network host -v etcd-data:/data -v $PWD/cluster.sh:/usr/bin/cluster.sh wbuntu/etcd:3.15.15 /usr/bin/cluster.sh

最后配置 etcdctl 访问三节点 etcd 集群：

➜  ~ export ETCDCTL_API=3
➜  ~ export ETCDCTL_ENDPOINTS=192.168.123.101:2379,192.168.123.102:2379,192.168.123.103:2379
➜  ~ etcdctl member list
5640a3d876739168, started, machine-3, http://192.168.123.103:2380, http://192.168.123.103:2379, false
cecb22d998638446, started, machine-2, http://192.168.123.102:2380, http://192.168.123.102:2379, false
cf50412f3d98e8eb, started, machine-1, http://192.168.123.101:2380, http://192.168.123.101:2379, false

4. 常用操作

4.1 添加和删除成员

参考文档：How to Add and Remove Members

添加和删除成员的前提是 etcd 集群处于正常运行状态，即包含 N 个成员的集群，有超过 (N-1)/2 成员处于健康状态。

首先从三节点集群中移除 192.168.123.103：

➜  ~ etcdctl endpoint status -w=table
+----------------------+------------------+---------+---------+-----------+------------+-----------+------------+--------------------+--------+
|       ENDPOINT       |        ID        | VERSION | DB SIZE | IS LEADER | IS LEARNER | RAFT TERM | RAFT INDEX | RAFT APPLIED INDEX | ERRORS |
+----------------------+------------------+---------+---------+-----------+------------+-----------+------------+--------------------+--------+
| 192.168.123.101:2379 |  d32a4b16a0f9191 |  3.5.15 |  1.9 MB |     false |      false |         8 |   17809240 |           17809240 |        |
| 192.168.123.102:2379 | 47c5ecfae8fccdb1 |  3.5.15 |  1.9 MB |      true |      false |         8 |   17809240 |           17809240 |        |
| 192.168.123.103:2379 |  96224218d3d7de4 |  3.5.15 |  1.9 MB |     false |      false |         8 |   17809240 |           17809240 |        |
+----------------------+------------------+---------+---------+-----------+------------+-----------+------------+--------------------+--------
➜  ~ etcdctl member remove 96224218d3d7de4
Member  96224218d3d7de4 removed from cluster a01e30bfaa44f6a5
➜  ~ export ETCDCTL_ENDPOINTS=192.168.123.101:2379,192.168.123.102:2379
➜  ~ etcdctl endpoint status -w=table
+----------------------+------------------+---------+---------+-----------+------------+-----------+------------+--------------------+--------+
|       ENDPOINT       |        ID        | VERSION | DB SIZE | IS LEADER | IS LEARNER | RAFT TERM | RAFT INDEX | RAFT APPLIED INDEX | ERRORS |
+----------------------+------------------+---------+---------+-----------+------------+-----------+------------+--------------------+--------+
| 192.168.123.101:2379 |  d32a4b16a0f9191 |  3.5.15 |  1.9 MB |     false |      false |         8 |   17809247 |           17809247 |        |
| 192.168.123.102:2379 | 47c5ecfae8fccdb1 |  3.5.15 |  1.9 MB |      true |      false |         8 |   17809247 |           17809247 |        |
+----------------------+------------------+---------+---------+-----------+------------+-----------+------------+--------------------+--------+

再添加一个新节点 192.168.123.104：

➜  ~ export ETCDCTL_ENDPOINTS=192.168.123.101:2379,192.168.123.102:2379
➜  ~ etcdctl member add machine-4 --peer-urls=http://192.168.123.104:2380
Member aabe77f74a8b8fd8 added to cluster a01e30bfaa44f6a5

ETCD_NAME="machine-4"
ETCD_INITIAL_CLUSTER="machine-1=http://192.168.123.101:2380,machine-2=http://192.168.123.102:2380,machine-4=http://192.168.123.104:2380"
ETCD_INITIAL_ADVERTISE_PEER_URLS="http://192.168.123.104:2380"
ETCD_INITIAL_CLUSTER_STATE="existing"

然后在 192.168.123.104 上使用启动 etcd，启动脚本如下，注意这里 CLUSTER_STATE 为 existing：

#!/bin/sh

TOKEN=tkn
CLUSTER_STATE=existing
NAME_1=machine-1
NAME_2=machine-2
NAME_4=machine-4
HOST_1=192.168.123.101
HOST_2=192.168.123.102
HOST_4=192.168.123.104
CLUSTER=${NAME_1}=http://${HOST_1}:2380,${NAME_2}=http://${HOST_2}:2380,${NAME_4}=http://${HOST_4}:2380

THIS_NAME=${NAME_4}
THIS_IP=${HOST_4}
etcd \
  --name ${THIS_NAME} \
  --data-dir etcd \
  --listen-client-urls http://${THIS_IP}:2379 \
  --advertise-client-urls http://${THIS_IP}:2379 \
  --listen-peer-urls http://${THIS_IP}:2380 \
  --initial-advertise-peer-urls http://${THIS_IP}:2380 \
  --initial-cluster ${CLUSTER} \
  --initial-cluster-state ${CLUSTER_STATE} \
  --initial-cluster-token ${TOKEN}

保存脚本为 cluster.sh 然后启动容器：

docker run --name etcd -d --restart unless-stopped --network host -v etcd-data:/data -v $PWD/cluster.sh:/usr/bin/cluster.sh wbuntu/etcd:3.15.15 /usr/bin/cluster.sh

最后检查集群状态，已恢复正常：

➜  ~ export ETCDCTL_ENDPOINTS=192.168.123.101:2379,192.168.123.102:2379,192.168.123.104:2379
➜  ~ etcdctl member list -w=table
+------------------+---------+-----------+-----------------------------+-----------------------------+------------+
|        ID        | STATUS  |   NAME    |         PEER ADDRS          |        CLIENT ADDRS         | IS LEARNER |
+------------------+---------+-----------+-----------------------------+-----------------------------+------------+
|  d32a4b16a0f9191 | started | machine-1 | http://192.168.123.101:2380 | http://192.168.123.101:2379 |      false |
| 47c5ecfae8fccdb1 | started | machine-2 | http://192.168.123.102:2380 | http://192.168.123.102:2379 |      false |
| aabe77f74a8b8fd8 | started | machine-4 | http://192.168.123.104:2380 | http://192.168.123.104:2379 |      false |
+------------------+---------+-----------+-----------------------------+-----------------------------+------------+

4.2 多节点缩容单节点

参考文档：

假如遭遇了严重故障，三节点 etcd 集群宕机了两节点而且无法恢复，如何将剩下的单节点恢复正常工作状态？如下所示，现在可以看到 etcd 集群的前两个节点已经宕机，剩下的一个节点报错：etcdserver: no leader

➜  ~ etcdctl endpoint status -w=table
{"level":"warn","ts":"2024-09-14T15:47:47.017106+0800","logger":"etcd-client","caller":"v3@v3.5.15/retry_interceptor.go:63","msg":"retrying of unary invoker failed","target":"etcd-endpoints://0xc0005a4000/192.168.123.101:2379","attempt":0,"error":"rpc error: code = DeadlineExceeded desc = latest balancer error: last connection error: connection error: desc = \"transport: Error while dialing: dial tcp 192.168.123.101:2379: connect: no route to host\""}
Failed to get the status of endpoint 192.168.123.101:2379 (context deadline exceeded)
{"level":"warn","ts":"2024-09-14T15:47:52.017513+0800","logger":"etcd-client","caller":"v3@v3.5.15/retry_interceptor.go:63","msg":"retrying of unary invoker failed","target":"etcd-endpoints://0xc0005a4000/192.168.123.101:2379","attempt":0,"error":"rpc error: code = DeadlineExceeded desc = latest balancer error: last connection error: connection error: desc = \"transport: Error while dialing: dial tcp 192.168.123.102:2379: connect: no route to host\""}
Failed to get the status of endpoint 192.168.123.102:2379 (context deadline exceeded)
+----------------------+------------------+---------+---------+-----------+------------+-----------+------------+--------------------+-----------------------+
|       ENDPOINT       |        ID        | VERSION | DB SIZE | IS LEADER | IS LEARNER | RAFT TERM | RAFT INDEX | RAFT APPLIED INDEX |        ERRORS         |
+----------------------+------------------+---------+---------+-----------+------------+-----------+------------+--------------------+-----------------------+
| 192.168.123.103:2379 | cba698a4889e4798 |  3.5.15 |  1.9 MB |     false |      false |        11 |   17809258 |           17809258 | etcdserver: no leader |
+----------------------+------------------+---------+---------+-----------+------------+-----------+------------+--------------------+-----------------------+

首先对剩下的单节点拍摄数据快照，保存为 db 文件，按 RAFT 一致性算法的数据同步机制，每个节点上都应该保存着完整数据备份，假如快照也无法拍摄，就尝试从 etcd 数据目录直接恢复，如果该目录数据也丢失，剩下的希望就是历史快照备份，一般都是定时备份到 S3 上的。

➜  ~ export ETCDCTL_ENDPOINTS=192.168.123.103:2379
➜  ~ etcdctl endpoint status -w=table
+----------------------+------------------+---------+---------+-----------+------------+-----------+------------+--------------------+-----------------------+
|       ENDPOINT       |        ID        | VERSION | DB SIZE | IS LEADER | IS LEARNER | RAFT TERM | RAFT INDEX | RAFT APPLIED INDEX |        ERRORS         |
+----------------------+------------------+---------+---------+-----------+------------+-----------+------------+--------------------+-----------------------+
| 192.168.123.103:2379 | cba698a4889e4798 |  3.5.15 |  1.9 MB |     false |      false |        11 |   17809258 |           17809258 | etcdserver: no leader |
+----------------------+------------------+---------+---------+-----------+------------+-----------+------------+--------------------+-----------------------+
➜  ~ etcdctl snapshot save etcd.db
{"level":"info","ts":"2024-09-14T15:52:19.780262+0800","caller":"snapshot/v3_snapshot.go:65","msg":"created temporary db file","path":"etcd.db.part"}
{"level":"info","ts":"2024-09-14T15:52:19.782948+0800","logger":"client","caller":"v3@v3.5.15/maintenance.go:212","msg":"opened snapshot stream; downloading"}
{"level":"info","ts":"2024-09-14T15:52:19.783015+0800","caller":"snapshot/v3_snapshot.go:73","msg":"fetching snapshot","endpoint":"192.168.123.103:2379"}
{"level":"info","ts":"2024-09-14T15:52:19.798245+0800","logger":"client","caller":"v3@v3.5.15/maintenance.go:220","msg":"completed snapshot read; closing"}
{"level":"info","ts":"2024-09-14T15:52:19.803647+0800","caller":"snapshot/v3_snapshot.go:88","msg":"fetched snapshot","endpoint":"192.168.123.103:2379","size":"1.9 MB","took":"now"}
{"level":"info","ts":"2024-09-14T15:52:19.803755+0800","caller":"snapshot/v3_snapshot.go:97","msg":"saved","path":"etcd.db"}
Snapshot saved at etcd.db

接下来停止该节点的 etcd 服务，清理数据，再还快照到指定目录，这里需要使用 etcdutl 从快照文件恢复数据：

➜  ~ docker ps -a
CONTAINER ID   IMAGE                 COMMAND                 CREATED          STATUS          PORTS     NAMES
d0642a2f7199   wbuntu/etcd:3.15.15   "/usr/bin/cluster.sh"   22 minutes ago   Up 22 minutes             etcd
➜  ~ docker stop etcd
etcd
➜  ~ docker volume ls
DRIVER    VOLUME NAME
local     etcd-data
➜  ~ docker volume inspect etcd-data
[
    {
        "CreatedAt": "2024-09-14T07:37:20Z",
        "Driver": "local",
        "Labels": null,
        "Mountpoint": "/var/lib/docker/volumes/etcd-data/_data",
        "Name": "etcd-data",
        "Options": null,
        "Scope": "local"
    }
]
➜  ~ tree /var/lib/docker/volumes/etcd-data/_data
/var/lib/docker/volumes/etcd-data/_data
`-- etcd
    `-- member
        |-- snap
        |   |-- 000000000000000a-00000000010fbf68.snap
        |   `-- db
        `-- wal
            |-- 0.tmp
            `-- 0000000000000000-0000000000000000.wal
➜  ~ mv /var/lib/docker/volumes/etcd-data/_data/etcd ./etcd_backup
➜  ~ etcdutl snapshot restore etcd.db --data-dir /var/lib/docker/volumes/etcd-data/_data/etcd
2024-09-14T08:11:11Z	info	snapshot/v3_snapshot.go:265	restoring snapshot	{"path": "etcd.db", "wal-dir": "/var/lib/docker/volumes/etcd-data/_data/etcd/member/wal", "data-dir": "/var/lib/docker/volumes/etcd-data/_data/etcd", "snap-dir": "/var/lib/docker/volumes/etcd-data/_data/etcd/member/snap", "initial-memory-map-size": 10737418240}
2024-09-14T08:11:11Z	info	membership/store.go:141	Trimming membership information from the backend...
2024-09-14T08:11:11Z	info	membership/cluster.go:421	added member	{"cluster-id": "cdf818194e3a8c32", "local-member-id": "0", "added-peer-id": "8e9e05c52164694d", "added-peer-peer-urls": ["http://localhost:2380"]}
2024-09-14T08:11:11Z	info	snapshot/v3_snapshot.go:293	restored snapshot	{"path": "etcd.db", "wal-dir": "/var/lib/docker/volumes/etcd-data/_data/etcd/member/wal", "data-dir": "/var/lib/docker/volumes/etcd-data/_data/etcd", "snap-dir": "/var/lib/docker/volumes/etcd-data/_data/etcd/member/snap", "initial-memory-map-size": 10737418240}
➜  ~ tree /var/lib/docker/volumes/etcd-data/_data
/var/lib/docker/volumes/etcd-data/_data
`-- etcd
    `-- member
        |-- snap
        |   |-- 0000000000000001-0000000000000001.snap
        |   `-- db
        `-- wal
            `-- 0000000000000000-0000000000000000.wal

然后修改 cluster.sh 配置，将当前节点作为单节点 etcd 集群启动：

#!/bin/sh

TOKEN=tkn
CLUSTER_STATE=new
NAME_3=machine-3
HOST_3=192.168.123.103
CLUSTER=${NAME_3}=http://${HOST_3}:2380

THIS_NAME=${NAME_3}
THIS_IP=${HOST_3}
etcd \
  --name ${THIS_NAME} \
  --data-dir etcd \
  --listen-client-urls http://${THIS_IP}:2379 \
  --advertise-client-urls http://${THIS_IP}:2379 \
  --listen-peer-urls http://${THIS_IP}:2380 \
  --initial-advertise-peer-urls http://${THIS_IP}:2380 \
  --initial-cluster ${CLUSTER} \
  --initial-cluster-state ${CLUSTER_STATE} \
  --initial-cluster-token ${TOKEN}

再使用 etcdctl 命令检查集群，可以看到节点恢复正常：

➜  ~ export ETCDCTL_ENDPOINTS=192.168.123.103:2379
➜  ~ etcdctl endpoint status -w=table
+----------------------+------------------+---------+---------+-----------+------------+-----------+------------+--------------------+--------+
|       ENDPOINT       |        ID        | VERSION | DB SIZE | IS LEADER | IS LEARNER | RAFT TERM | RAFT INDEX | RAFT APPLIED INDEX | ERRORS |
+----------------------+------------------+---------+---------+-----------+------------+-----------+------------+--------------------+--------+
| 192.168.123.103:2379 | 8e9e05c52164694d |  3.5.15 |  1.9 MB |      true |      false |         2 |          4 |                  4 |        |
+----------------------+------------------+---------+---------+-----------+------------+-----------+------------+--------------------+--------+

最后是修复容器集群，上述的三节点 etcd 集群是我的 K3s 集群的外部 etcd 存储，这里只需要修改 K3s 服务外部 etcd 地址，保留 192.168.123.103:2379，然后重启 K3s 进程恢复容器集群，如下：

➜  ~ grep ExecStart= -A9 /etc/systemd/system/k3s.service
ExecStart=/usr/local/bin/k3s \
    server \
	'--datastore-endpoint' \
	'http://192.168.123.103:2379' \
	'--tls-san=192.168.123.90' \
    '--kube-apiserver-arg=--max-requests-inflight=800' \
    '--kube-apiserver-arg=--max-mutating-requests-inflight=400' \
    '--kube-controller-manager-arg=--kube-api-qps=100' \
    '--kube-scheduler-arg=--kube-api-qps=200' \
    '--kubelet-arg=--kube-api-qps=100' \
➜  ~ systemctl daemon-reload
➜  ~ systemctl restart k3s
➜  ~ kubectl get pod -A
NAMESPACE     NAME                                      READY   STATUS      RESTARTS        AGE
kube-system   coredns-8b9777675-2phdr                   1/1     Running     4 (3m55s ago)   27d
kube-system   helm-install-traefik-crd-5v247            0/1     Completed   0               27d
kube-system   helm-install-traefik-sfbxv                0/1     Completed   2               27d
kube-system   local-path-provisioner-69dff9496c-xtt22   1/1     Running     8 (3m21s ago)   27d
kube-system   metrics-server-854c559bd-gz2pw            1/1     Running     8 (3m21s ago)   27d
kube-system   svclb-traefik-3d992c42-6qkrl              2/2     Running     8 (3m55s ago)   27d
kube-system   traefik-54c4f4ffd8-wnzgv                  1/1     Running     4 (3m55s ago)   27d
